D&B Audiotechnik V7P – 3-Way Passive Point Source Loudspeaker (V-Series)

Name: FFA6004 | Electronic Space
Price: 1300 EUR
Availability: InStock

The D&B Audiotechnik V7P is a high-performance 3-way passive point source loudspeaker designed for applications requiring strong direct projection, high SPL, and controlled dispersion without the complexity of line arrays.

Positioned within the V-Series ecosystem, the V7P is engineered to deliver full-range sound from a single enclosure, making it ideal for touring, live venues, theaters, and installations across Europe where clarity, power, and flexibility are essential.

Unlike line array systems, the V7P focuses on direct sound delivery, offering a tight, controlled coverage pattern with excellent vocal clarity and midrange detail, even at high output levels.

Key Specifications

Configuration: 3-way passive point source loudspeaker

Drivers:

2 × 10″ LF drivers (dipole arrangement)
1 × 8″ MF driver (horn-loaded)
1 × 1.4″ HF compression driver

Dispersion: 75° × 40° constant directivity (rotatable horn)

Frequency Response (–5 dB):

Standard mode: 59 Hz – 18 kHz
CUT mode: 100 Hz – 18 kHz

Max SPL (1 m, free-field):

Up to 140 dB (with D80 / D40 amplifiers)

Power Handling: 500 W RMS / 2000 W peak
Nominal Impedance: 8 Ω

Amplifier Compatibility: D20, D40, D80, D90, 30D, 40D

Physical & Mechanical Details

Construction: Marine plywood enclosure with PCP (Polyurea Cabinet Protection) finish
Grille: Steel front grille with acoustically transparent foam backing

Rigging & Mounting:

Multiple M10 threaded inserts for brackets and rigging
Additional sockets for load pins and safety attachments
Compatible with flying frames, wall mounts, and stands

Dimensions (H × W × D): ~700 × 308 × 466 mm
Weight: ~33 kg

Connectors:

2 × NLT4 F/M
Optional NL4 or EP5 configurations

Key Features & Configuration

3-Way Passive Design:
The V7P integrates LF, MF, and HF drivers into a single enclosure, ensuring smooth crossover transitions and full-range performance without external processing complexity.

Dipole LF Driver Arrangement:
The dual 10″ LF drivers are arranged symmetrically, providing controlled dispersion down to lower frequencies (~350 Hz) and reducing unwanted rear radiation.

Horn-Loaded Midrange Section:
The 8″ MF driver is coupled to a horn, delivering:

High sensitivity in the vocal range
Exceptional clarity for speech and live music
Strong presence even at long distances

Rotatable Constant Directivity Horn:
The HF horn can be rotated by 90°, allowing:

Horizontal or vertical deployment
Flexible coverage adaptation
Consistent tonal balance regardless of orientation

Coverage & Acoustic Behavior

Nominal Coverage:

75° horizontal × 40° vertical

Practical Coverage Advantage

Focused sound projection
Reduced spill outside coverage area
Better control in reflective environments

Real-World Behavior

In live applications:

Strong vocal intelligibility across the audience
Consistent tonal balance within the coverage zone
Minimal need for corrective EQ due to controlled dispersion

System Configuration & Deployment

Typical System Setup

2–4 × V7P per side (small to medium systems)
4–8 × V7P per side (larger systems)
Subwoofer support (V-SUB or V-GSub)

Deployment Options

Standalone Full-Range System:
Used as main PA for small to medium events.

Clustered Systems:
Multiple cabinets combined for increased coverage and output.

Flown Systems:
Integrated into truss setups using dedicated rigging hardware.

Hybrid Systems:
Combined with V-Series line arrays (V8/V12) as fills or delays.

Low-Frequency Integration

The V7P is typically paired with:

V-SUB or V-GSub subwoofers
Cardioid sub configurations for controlled bass

Practical Result

Extended low-frequency response below 59 Hz
Balanced full-range system performance
Controlled bass energy in challenging environments

Acoustic Modes & DSP Integration

When used with d&b amplifiers, the V7P supports:

CUT Mode:
Reduces low-frequency output when used with subwoofers.

HFC (High-Frequency Compensation):
Maintains clarity over long distances.

CPL (Coupling):
Balances low-frequency buildup in multi-cabinet setups.

System Advantage

Faster system tuning
Consistent performance across venues
Reduced need for external processing

Ideal Applications

Touring and rental systems
Live music venues and clubs
Theaters and performing arts spaces
Corporate and conference environments
Houses of worship
Outdoor events requiring direct projection

Performance Characteristics

The V7P is known for:

High output with low distortion
Strong vocal clarity and midrange presence
Controlled dispersion and focused projection
Balanced full-range performance from a single enclosure

Field Insight

In real-world deployments:

The V7P delivers “line array-like clarity” without array complexity
Systems require fewer cabinets compared to smaller point source solutions
Coverage remains consistent even in acoustically challenging venues

System Advantages in Practice

Simplicity:
No complex array calculations required.

Flexibility:
Works as standalone, cluster, or integrated system.

Efficiency:
High output from a single cabinet reduces system size.

Reliability:
Proven performance in touring and installation environments.

Summary

The D&B Audiotechnik V7P is a powerful, full-range point source loudspeaker combining high output, precise dispersion, and flexible deployment options within the V-Series ecosystem.

Bottom Line

For professional audio applications in Europe, the V7P offers a high-impact alternative to smaller line arrays, delivering clear, controlled sound with minimal setup complexity, making it a strong choice for both touring and installation systems.
