D&B Audiotechnik Q Bracket – Rigging & Mounting Accessory (Q-Series)

The D&B Q Bracket is a professional mounting and rigging accessory designed for precise positioning and safe installation of Q-Series loudspeakers. It enables flexible deployment in both touring and fixed installations, supporting wall mounting, ceiling suspension, and truss-based rigging.

Engineered by d&b audiotechnik, the Q Bracket ensures accurate speaker alignment, secure load handling, and consistent coverage performance when working with Q-Series systems such as Q7 and Q10.

---

Key Specifications

Mounting Type: Multi-purpose bracket (wall, ceiling, truss)
Compatibility: Q7, Q10, Qi Series loudspeakers
Adjustment Range: Variable vertical and horizontal tilt
Load Capacity: Designed for single cabinet mounting (subject to rigging standards)
Rigging Points: Integrated fixing points for clamps, eyebolts, and safety attachments
Finish: Durable black powder-coated steel
Application Type: Fixed installation and touring use

---

Physical & Mechanical Details

Construction: High-strength steel frame for structural integrity
Finish: Impact-resistant black coating for touring durability
Mounting Interface: Direct cabinet attachment with secure locking points
Safety: Supports secondary safety attachment (mandatory in professional use)
Weight: Approx. 5–8 kg (varies by model/configuration)

---

Key Features & Configuration

Multi-Position Mounting:
Supports wall, ceiling, and truss installations, allowing speakers to be deployed in a wide range of environments.

Adjustable Angle Control:
Enables precise vertical and horizontal aiming of loudspeakers, ensuring optimal coverage and minimizing reflections.

Touring Compatibility:
Designed for fast deployment using clamps and rigging hardware, making it suitable for mobile event setups.

Secure Load Handling:
Engineered to safely support Q-Series cabinets when installed according to d&b rigging guidelines.

---

System Integration

Used in combination with:

• Q7 and Q10 loudspeakers
• d&b amplifiers (D12, D20, D80)
• Truss clamps and rigging accessories

The Q Bracket ensures that loudspeakers are correctly positioned for optimal system performance, directly impacting sound distribution and coverage accuracy.

---

Practical Deployment Scenarios

Fixed Installation:
Mounted in clubs, theaters, or venues where permanent speaker positioning is required with clean visual integration.

Touring & Events:
Used with truss systems for temporary setups, enabling fast rigging and flexible positioning.

Distributed Systems:
Allows multiple speakers to be placed strategically across a venue for consistent coverage.

---

Why the Q Bracket Matters

Speaker positioning is critical in professional audio. The Q Bracket allows:

• Accurate aiming of sound toward the audience
• Reduction of unwanted reflections
• Improved overall system clarity

In real-world applications, correct rigging can significantly reduce the need for corrective EQ and system adjustments.

---

Ideal Applications

Q-Series touring systems
Fixed installations in venues and clubs
Corporate and event setups requiring precise speaker placement
Situations where safe and flexible rigging is essential

---

Summary

The D&B Audiotechnik Q Bracket is a critical rigging component for Q-Series loudspeakers, providing safe mounting, flexible positioning, and improved acoustic performance.

Its robust construction, adjustable design, and compatibility with professional rigging systems make it an essential accessory for both touring and installation environments.
